IBM P780 (9179-MHB)
| 安装类型 | 机架式 |
| 高度 | 4U-16U |
| CPU信息 | 16C 3.86GHz 或者 8-core 4.14GHz (TurboCore)，最大可达64C |
| CPU类型 | POWER7 |
| CPU插槽数 | 单个柜子1个CPU笼子，最大支持4个柜子连接 |
| CPU激活 | 需要对应VPD |
| 硬盘信息 | 单柜硬盘背板数量为 1 |
| 最大硬盘数量 | 单柜最大六个硬盘 |
| 内存参数 | DDR3 |
| 支持内存容量范围 | 单个柜子最大512GB内存，整机最高可达2TB。 |
| 内存插槽数量 | 内存插槽在CPU笼子上，单个CPU笼子有16个插槽，4个柜子最多64个插槽 |
| 内存是否需要激活 | 需要激活码 |
| 电源参数 | 200v 到 240v 交流。 |
| 单机电源数量 | 2 |
| 介质托架 | 1 个薄型 SATA DVD-RAM 的托架。 |
| 适配器插槽 | 6 个 PCI Express 8x 插槽。 |
| 端口 | 可选的 4 口的千兆网卡，或双口的 10 Gb 网卡和双口的千兆网卡，3 个 USB 端口，2 个 HMC 端口，2 个 SPCN 端口。 |
| IO适配器 | 2 个 SAS DASD/SSD 控制器，1 个 SATA 媒体控制器。 |
| IO扩展 | 最多 4 个 PCIe 12x I/O 抽屉，最多 8 个 PCI-x DDR 12x I/O 抽屉。 |
| 发布日期 | 2010/3/16 |
| 下架日期 | 2012/8/31 |
| 服务截止期 | |
| 操作系统 | AIX, IBM i, and LinuX f或者 Power。 |
| 产品尺寸 | Height: 174 mm, Depth: 863 mm, Width: 483 mm |
| 产品重量 | 70.3 千克（155 磅） |
| FC号 | PN号 | 描述 |
| CPU | ||
| 4982 |
536E 74Y4874 74Y4913 |
3.86GHz / 4.14 GHz TurboCore Proc Card, 0/16 Core POWER7, 16 DDR3 Memory Slots |
| 系统板 | ||
|
497B 74Y5976 |
System backplane FRU kit (9117-MMB and 9179-MHB) | |
|
52B7 46K8127 |
VPD card | |
| 内存 | ||
| 5600 |
31CB 45D5670 45D7238 |
0/32GB DDR3 Memory (4x8GB) DIMMS - 1066MHz - POWER7 CoD Memory |
| 5601 |
31CC 45D5674 45D7242 |
0/64GB DDR3 Memory (4x16GB) DIMMS - 1066MHz - POWER7 CoD Memory |
| 5602 |
31D6 45D7248 45D8424 |
0/128GB DDR3 Memory (4x32GB) DIMMS - 1066MHz - POWER7 CoD Memory |
| 硬盘 | ||
|
19A3 74Y4897 |
571 GB 10K small form factor SAS disk drive (IBM® i) | |
|
19A4 74Y9271 |
857 GB 10K small form factor SAS disk drive (IBM i) | |
|
58B3 74Y5293 74Y5294 |
177 GB small form factor solid-state SAS drive for 9117-MMC, 9117-MMD, 9179-MHC, or 9179-MHD. |
|
|
58B8 74Y9524 |
387 GB small form factor solid-state SAS drive | |
|
58B9 74Y9526 |
387 GB small form factor solid-state SAS drive | |
| 74Y4900 | 600 GB 10K small form factor SAS disk drive | |
| 74Y9272 | 900 GB 10K small form factor SAS disk drive | |
| 1790 | 600GB 10K RPM SAS SFF Disk Drive (AIX/Linux) | |
| 1793 | 177GB SFF-2 SSD w/ eMLC (AIX/Linux) | |
| 1881 |
42R5660 42R8389 42R8391 42V7387 44V7388 |
73.4GB 10K RPM SAS SFF Disk Drive |
| 1882 |
42R5661 42R8390 42R8392 46V6830 46V6837 |
146.8GB 10K RPM SAS SFF Disk Drive |
| 1883 |
44V4426 44V4427 44V4428 44V6842 |
73.4 GB 15K RPM SAS SFF Disk Drive |
| 1884 |
198B 44V4429 44V4430 |
69.7 GB 15K RPM SAS SFF Disk Drive |
| 1885 |
42R6833 44V6831 44V6833 44V6838 |
300GB 10K RPM SFF SAS Disk Drive |
| 1886 |
44V6843 44V6845 44V6850 |
146GB 15K RPM SFF SAS Disk Drive |
| 1888 |
198C 44V6844 00E6166 |
139 GB 15K small form factor SAS disk drive, IBM® i |
| 1890/1909 |
58B0 44V6817 44V6821 44V8674 |
69GB SFF SAS Solid State Drive |
| 1911 |
198D 74Y4896 |
283GB 10K RPM SFF SAS Disk Drive (IBM i) |
| 1917 | 146GB 15k RPM SAS SFF-2 Disk Drive (AIX/Linux) | |
| 1925 | 300GB 10k RPM SAS SFF-2 Disk Drive (AIX/Linux) | |
| 1964 | 600GB 10k RPM SAS SFF-2 Disk Drive (AIX/Linux) | |
| 1995 |
58B2 43W7749 |
177GB SSD Module with eMLC (AIX/Linux) |
| 3586 |
58B0 44V6819 44V8673 |
69GB 3.5" SAS Solid State Drive |
| 3647 |
10N7203 10N7204 10N7232 42R4234 |
146 GB 15K RPM SAS Disk Drive |
| 3648 |
10N7207 10N7208 10N7234 42R5648 |
300 GB 15K RPM SAS Disk Drive |
| 3649 |
44V4432 44V4433 44V4438 44V4440 |
450 GB 15K RPM SAS Disk Drive |
| 4367 | Bundle: 5 x #2055 and 20 x #1995 (AIX/Linux) | |
| 硬盘背板 | ||
|
2BBE 74Y5511 |
Small form factor SAS disk drive backplane with embedded SAS adapters. | |
| RAID卡 | ||
| 2055 |
43K6366 43K6367 74Y6409 |
PCIe RAID & SSD SAS Adapter 3Gb w/ Blind Swap Cassette |
| 5662 |
2BC2 42R8705 46K6472 74Y6441 |
175MB Cache RAID - Dual IOA Enablement Card |
| 5805 | PCIe 380MB Cache Dual - x4 3Gb SAS RAID Adapter | |
| 5900 |
42R7988 42R7989 44V3296 44V4266 44V4404 |
PCI-X DDR Dual - x4 3Gb SAS Adapter |
| 5902 |
572B 44V4203 44V5194 97P4847 |
PCI-X DDR Dual-x4 3Gb SAS RAID Adapter, Cache battery pack 39J5555. |
| 5903 |
574E 44V4198 44V7436 44V7597 74Y6124 |
PCIe 380MB Cache Dual - x4 3Gb SAS RAID Adapter |
| 5908 |
42R3965 42T3969 44V4577 44V4579 44V5193 44V8622 46K4734 46K6114 74Y5665 |
PCI-X DDR 1.5GB Cache SAS RAID Adapter (BSC) |
| 5912 |
572A 44V4413 4V4414 44V5195 44V8579 |
PCI-X DDR Dual - x4 SAS Adapter |
| 5913 |
11P1346 11P3896 |
PCIe2 1.8GB Cache RAID SAS Adapter Tri-port 6Gb |
| 5922 |
11P1347 11P3897 |
Non-paired SAS RAID indicator |
| 5923 | Non-paired PCIe SAS RAID Indicator | |
| 5924 | Non-paired 6Gb/s PCIe SAS RAID Indicator | |
| SCSI卡 | ||
| 1912 |
39J2421 39J4998 42R4862 42R4362 52P8558 |
PCI-X DDR Dual Channel Ultra320 LVD SCSI Adapter |
| 5736 |
39J1643 39J2862 39J3536 39J4996 39J5022 42R4860 42R8736 44V5591 42R4362 52P8558 |
PCI-X DDR 2.0 Dual Channel Ultra320 SCSI Adapter |
| 5901 |
57B3 44V4852 44V8580 45K4732 |
PCIe Dual-x4 SAS Adapter |
| 网卡 | ||
|
2BC6 46K5534 |
Optical - 2 x 1 GbE and 2 x 10 GbE Host Ethernet Adapter card | |
| 1803 |
2BC4 46K5965 46K6484 |
4 x 1 GbE Host Ethernet Adapter card (4x 1Gb RJ-45) |
| 5700 |
00P3055 00P4499 03N6981 05N6768 09P5386 10N8586 11P3847 12R9314 15R7536 |
IBM Gigabit Ethernet-SX PCI-X Adapter |
| 5706 |
00G2380 00P4289 00P6131 03N5297 03N6070 53P5450 80P4024 80P7033 |
IBM 2-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter |
| 5717 |
10N7405 10N8556 46Y3512 |
4-Port 10/100/1000 Base-TX PCI Express Adapter |
| 5721 |
573A 03N4590 05N6768 10N8264 10N9774 10N9775 11P3847 12R9314 15R75836 74Y2621 80P6636 80P7055 |
10 Gb Ethernet-SR PCI-X 2.0 DDR Adapter |
| 5722 |
576A 03H4588 10N8263 10N9776 10N9777 12R6249 12R9315 80P6634 80P7053 |
10 Gb Ethernet-LR PCI-X 2.0 DDR Adapter |
| 5732 |
45D4771 46K6696 46K7899 |
10 Gigabit Ethernet-CX4 PCIe (x8)Adapter |
| 5740 | 03N5444 | 4-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter |
| 5767 |
10N6845 10N7405 46K6601 |
2-Port 10/100/1000 Base-TX Ethernet PCI Express Adapter |
| 5768 |
05H6768 10N6846 11P3847 12R9314 15R7536 46K6602 |
2-Port Gigabit Ethernet-SX PCI Express Adapter |
| 5769 |
05N6768 10N9505 11P3847 12R9314 46K7897 |
10 Gigabit Ethernet-CX4 PCIe (x8)Adapter |
| 5772 |
576E 05N6768 10N9034 11P3847 12R9314 |
10 Gigabit Ethernet-CX4 PCIe (x8)Adapter |
| 5899 | (#5899) -PCIe2 4-port 1GbE Adapter | |
| 适配卡 | ||
|
2A14 46K7288 |
TPMD card | |
| 1808 |
2BC3 45D7063 74Y5398 |
GX++ 12X DDR Adapter, Dual-port |
| 2728 |
57D1 46K6692 46K7494 |
4 port USB PCIe Adapter |
| 2943 |
07L9001 07L9822 11H5967 11H5968 11H5969 11H6011 42R4761 6298964 93H6540 93H6541 94H6541 |
8-Port Asynchronous Adapter EIA-232/RS-422, PCI bus |
| 4764 |
12R6540 12R6714 41U0441 41U0442 41V0161 |
PCI-X Cryptographic Coprocessor (FIPS 4) |
| 4808 |
45D5803 45D6680 45D7948 |
PCIe Crypto Coprocessor Gen3 BSC 4765-001 |
| 4809 |
45D5803 45D6680 45D7948 46K5440 |
PCIe Crypto Coprocessor Gen4 BSC 4765-001 |
| 5285 | (#5285) -PCIe2 2-Port 4X IB QDR Adapter 40Gb | |
| 5664 |
2BBB 74Y2418 |
Service Processor, FSP card (drawers 1 and 2) |
| 5665 |
2BBC 44V8599 46K6476 |
FSP/Clock Pass Through Card, FSP Passthru card (drawers 3 and 4) |
| 5744 | (#5744) -PCIe2 4-Port 10GbE&1GbE SR&RJ45 Adapter | |
| 5745 | (#5745) -PCIe2 4-Port 10GbE&1GbE SFP+Copper&RJ45 Adapter | |
| 5785 |
57D2 42R5143 46K6734 46K6735 6298965 |
4 Port Async EIA-232 PCIe Adapter |
| 6805 |
21P5267 39J2298 53P1677 |
PCI 2-Line WAN IOA No IOP |
| 显卡 | ||
| 5748 | 10N7756 | POWER GXT145 PCI Express Graphics Accelerator |
| 光纤卡 | ||
| 5708 |
2B3B 05N6768 11P3847 12R9314 46K8088 |
10Gb FCoE PCIe Dual Port Adapter |
| 5713 |
03N6056 26K6490 30R5219 32R1926 46K7342 49Y4236 |
1 Gigabit iSCSI TOE PCI-X on Copper Media Adapter |
| 5714 |
03N6058 30R5519 |
1 Gigabit iSCSI TOE PCI-X on Optical Media Adapter |
| 5716 |
280B 03N6441 03N7069 05N6768 10N8622 11P3847 12R9314 15R7536 80P4543 80P4544 |
2 Gigabit Fibre Channel PCI-X Adapter |
| 5729 | (#5729) -PCIe2 8Gb 4-port Fibre Channel Adapter | |
| 5735 |
577D 05N6768 10N9824 11P3847 12R9314 46C7006 |
8 Gigabit PCI Express Dual Port Fibre Channel Adapter |
| 5749 |
2B30 05N6768 11P3847 12R9314 32N1294 |
4Gbps Fibre Channel (2-Port) |
| 5759 |
03N5027 03N5029 03N6768 10N8620 10N3847 12R9314 |
4 Gb Dual-Port Fibre Channel PCI-X 2.0 DDR Adapter |
| 5773 |
05N6768 10N7249 44P3847 12R9314 15R7536 |
4 Gigabit PCI Express Single Port Fibre Channel Adapter |
| 5774 |
05N6768 10N7255 11P3847 12R9314 15R7536 |
4 Gigabit PCI Express Dual Port Fibre Channel Adapter |
| 电源 | ||
| 5632 | 74Y4926 | System AC Power Supply, 1725 W |
| 稳压模块 | ||
|
2BC7 46K5854 |
Processor voltage regulator module (VRM) | |
|
2BC8 46K5856 |
Memory VRM | |
|
2BC9 46K5858 |
Processor card regulator 1 (40P) | |
|
2BCA 46K5860 |
Processor card regulator 3 (20P) | |
| 电池 | ||
| 016G8095 | Time-of-day battery | |
| 光驱 | ||
| 5762 |
44V4219 44V4220 |
SATA Slimline DVD-RAM Drive |
| 风扇 | ||
| 46K4939 | Fan assembly (single fan) | |
| 导轨 | ||
| 46K6362 | Rack rail kit | |
| 6586 |
10N7683 80P3263 |
Modem Tray for 19-Inch Rack |
| 7841 | Ruggedize Rack Kit | |
| 线缆 | ||
| 1025 |
42R5087 43L6774 75G3801 87G6236 |
Modem Cable - US/Canada and General Use |
| 1466 |
21F9359 22R5222 |
30m SPCN Cable |
| 1815 | 44V7563 | SAS Cable for triple split DASD backplane |
| 1819 | 44V7564 | SAS Cable Assembly for SAS Port |
| 1828 |
15R8139 45D2235 |
1.5 Meter 12X to 4X Channel Conversion Cable |
| 1829 |
41V0226 42V2129 |
0.6 Meter 12X Cable |
| 1830 |
41V0227 42R6153 42V3130 |
1.5 Meter 12X cable |
| 1834 |
39J5642 42R6157 42R6160 |
8.0 Meter 12X Cable |
| 1840 | 42V2132 | 3.0 Meter 12X Cable |
| 1841 |
15R8140 45D2236 |
3 Meter 12X to 4X Channel Conversion Cable |
| 1842 |
15R8141 45D2237 |
10 Meter 12X to 4X Channel Conversion Cable |
| 1854 | 10 Meter 12X to 4X Enhanced Channel Conversion Cable | |
| 1861 |
44V3421 45D4785 |
0.6 Meter 12X DDR Cable |
| 1862 |
44V3423 45D4786 |
1.5 Meter 12X DDR Cable |
| 1864 | 45D4788 | 8.0 Meter 12X DDR Cable |
| 1865 |
44V3426 45D2571 45D5271 |
3.0 Meter 12X DDR Cable |
| 2118 |
01K6497 07L9628 76H0518 |
Converter Cable VHDCI to P Mini-68 pin to 68 pin 0.3M |
| 2124 |
09L3299 36R2585 41Y0596 |
Ultra 320 SCSI Cable 1 Meter |
| 2125 |
09L3301 36R2576 41Y0597 |
Ultra 320 SCSI Cable 3 Meter |
| 2126 |
09L3303 36R2577 41Y0598 |
Ultra 320 SCSI Cable 5 Meter |
| 2127 |
09L0881 09L3305 36R2578 41Y0599 |
Ultra 320 SCSI Cable 10 Meter |
| 2128 |
09L3307 19P1904 36R2579 41Y0600 |
Ultra 320 SCSI Cable 20 Meter |
| 2138 |
41Y0601 42D9817 |
0.55 Meter Ultra 320 SCSI Cable |
| 2456 |
09P3044 11P1352 11P1373 12R9321 |
LC-SC 50 Micron Fiber Converter Cable |
| 2459 |
00P4023 11P1374 12R9322 |
LC-SC 62.5 Micron Fiber Converter Cable |
| 2861 |
07L8817 87H3404 87H3405 87H3406 87H3439 87H3568 |
ARTIC960Hx 4-Port EIA-232 Cable |
| 2863 |
53G0638 87H3407 87H3408 87H3409 87H3566 |
ARTIC960Hx 4-Port X.21 Cable |
| 2864 |
87H3398 87H3399 87H3400 87H3442 87H3565 |
ARTIC960Hx 4-Port V.35 (DTE Cable |
| 2934 |
10N6535 12H1204 40H0744 40H2206 |
Asynchronous Terminal/Printer Cable EIA-232 |
| 2936 |
30F9453 42R5206 53F3205 53F3662 6223741 6323741 |
Asynchronous Cable EIA-232/V.24 |
| 2951 |
33F8985 93H2899 93H5263 |
Cable V.24 / EIA-232 |
| 2952 |
71F0163 93H2900 93H5264 |
Cable V.35 |
| 2953 |
73H2508 93H2901 93H5265 |
Cable V.36 / EIA-499 |
| 2954 |
40F9904 93H2902 93H5267 |
Cable X.21 |
| 3124 |
10N7158 88G4771 88G4853 |
Serial to Serial Port Cable for Drawer/Drawer |
| 3125 |
10N7159 88G4772 88G4854 |
Serial to Serial Port Cable for Rack/Rack |
| 3652 |
42R6762 44V4147 |
SAS Cable (EE Drawer to Drawer 1M |
| 3653 |
42R6727 44V4148 |
SAS Cable (EE) Drawer to Drawer 3M |
| 3654 |
42R6728 44V4149 |
SAS Cable (EE) Drawer to Drawer 6M |
| 3661 |
42R6742 44V4154 |
SAS Cable (X Adapter to SAS Enclosure Dual Controller/ Dual Path 3M |
| 3662 |
42R6743 44V4155 |
SAS Cable (X) Adapter to SAS Enclosure, Dual Controller/ Dual Path 6M |
| 3663 |
42R6744 44V4156 |
SAS Cable (X) Adapter to SAS Enclosure, Dual Controller/ Dual Path 15M |
| 3671 | 44V6218 | Serv Interface Cable-2, 3, and 4 Enclosure |
| 3672 | 44V6219 | Serv Interface Cable-3 and 4 Enclosure |
| 3673 | 44V6220 | Serv Interface Cable-4 Enclosure |
| 3679 |
42R6751 44V4041 |
SAS Cable (AI)-1M |
| 3681 |
44V4151 44V8231 |
3M SAS CABLE, ADPTR TO ADPTR (AA) |
| 3682 |
44V4152 44V8230 |
6M SAS CABLE, ADPTR TO ADPTR (AA) |
| 3684 |
42R8118 44V4163 |
SAS Cable (AE Adapter to Enclosure single controller/ single path 3M |
| 3685 |
42R8120 44V4164 |
SAS Cable (AE) Adapter to Enclosure, single controller/ single path 6M |
| 3686 |
42R6792 44V4161 |
SAS Cable (YI) System to SAS Enclosure, Single Controller/Dual Path 1.5M |
| 3687 |
42R6793 44V4162 |
SAS Cable (YI) System to SAS Enclosure, Single Controller/Dual Path 3M |
| 3688 | 44V5132 | SAS Cable (AT 0.6 Meter) |
| 3691 |
42R6788 44V4157 |
SAS Cable (YO Adapter to SAS Enclosure Single Controller/Dual Path 1.5 M |
| 3692 |
42R6789 44V4158 |
SAS Cable (YO) Adapter to SAS Enclosure, Single Controller/Dual Path 3 M |
| 3693 |
42R6790 44V4159 |
SAS Cable (YO) Adapter to SAS Enclosure, Single Controller/Dual Path 6 M |
| 3694 |
42R6791 44V4160 |
SAS Cable (YO) Adapter to SAS Enclosure, Single Controller/Dual Path 15 M |
| 3711 | 44V6211 | Processor Cable, Two-Drawer System |
| 3712 | 44V6212 | Processor Cable, Two, Three or Four Drawer System |
| 3713 |
44V6213 44V6214 |
Processor Cable, Three or Four Drawer System |
| 3714 |
44V7639 44V7641 44V7643 |
Processor Cable, Four-Drawer System |
| 3925 |
00P2165 23R4632 40H6328 40H6329 |
Serial Port Converter Cable 9-Pin to 25-Pin |
| 3926 | 00P2166 | Asynch Printer/Terminal Cable 9-pin to 25-pin 4M |
| 3927 | 10N7712 | Serial Port Null Modem Cable 9-pin to 9-pin 3.7M |
| 3928 | 10N7713 | Serial Port Null Modem Cable 9-pin to 9-pin 10M |
| 4242 |
07L9633 08L0491 42R4755 |
6 Foot Extender Cable for Displays (15 pin D-shell to 15 pin D-shell |
| 4256 |
00P2969 10N7374 32N1311 44P1375 |
Extender Cable - USB Keyboards 2M |
| 6001 |
00G1277 42F6839 |
Power Control Cable (SPCN-2 meter) |
| 6006 |
09P1251 22R5239 93H8045 |
Power Control Cable (SPCN-3 meter) |
| 6007 |
21F9358 22R5221 55F4533 |
Power Control Cable (SPCN 15 meter) |
| 6008 |
21F9469 22R5219 55F4532 74F0188 |
Power Control Cable (SPCN 6 meter) |
| 6029 |
21F9359 22R5222 |
Power Control Cable (SPCN 30 meter) |
| 6458 | Power Cable- Drawer to IBM PDU 14-foot 250V/10A | |
| 6460 | Power Cord (14-foot Drawer To OEM PDU (125V 15A Plug Type #4 | |
| 6469 | Power Cord (14-foot Drawer to OEM PDU (250V 15A United States Plug Type #5 | |
| 6470 | Power Cord (6-foot To Wall (125V 15A Plug Type #4 | |
| 6471 | Power Cord (9-foot To Wall/OEM PDU (125V 15A Plug Type #70 | |
| 6472 | Power Cord (9-foot To Wall/OEM PDU (250V 16A Plug Type #18 | |
| 6473 | Power Cord (9-foot To Wall/OEM PDU (250V 10A Plug Type 19 | |
| 6474 | Power Cord (9-foot) To Wall/OEM PDU (250V 13A) Plug Type #23 | |
| 6475 | Power Cord (9-foot) To Wall/OEM PDU (250V 16A) Plug Type #32 | |
| 6476 | Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #24 | |
| 6477 | Power Cord (9-foot) To Wall/OEM PDU (250V 16A) Plug Type #22 | |
| 6478 | Power Cord (9-foot) To Wall/OEM PDU (250V 16A) Plug Type #25 | |
| 6479 | Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #6 | |
| 6487 | Power Cord (6-foot To Wall (250V 15A United States Plug Type #5 | |
| 6488 | Power Cord (9-foot To Wall/OEM PDU (125V 15A or 250V 10A Plug Type #2 | |
| 6493 | Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #62 | |
| 6494 | Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #69 | |
| 6495 | Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #73 | |
| 6496 | Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #66 | |
| 6497 | Power Cord (6-foot) To Wall/OEM PDU (250V 10A) Plug Type #10 | |
| 6498 | Power Cord (6-foot) To Wall/OEM PDU (250V 15A) Plug Type #34 | |
| 6651 | Power Cord (9-foot To Wall/OEM PDU (125V 15A Plug Type #75 | |
| 6659 | Power Cord (9-foot To Wall/OEM PDU (250V 15A Plug Type #76 | |
| 6660 | Power Cord (14-foot Drawer To OEM PDU (125V 15A Plug Type #59 (DENAN marking | |
| 6664 | 7-Ft 200V PDU Power Cable | |
| 6665 | Power Cord 3 M (10 ft Drawer to IBM PDU 250V/10A | |
| 6669 | Power Cord (14-foot Drawer to OEM PDU (250V 15A Plug Type #57 (DENAN marking | |
| 6670 | Power Cord (6-foot To Wall (125V 15A Plug Type #59 (DENAN marking | |
| 6671 | Power Cord (9-foot) Drawer to IBM PDU 250V/10A | |
| 6672 | Power Cord (5-foot) Drawer to IBM PDU 250V/10A | |
| 6680 | Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #6 Insulated | |
| 6687 | Power Cord (6-foot) To Wall (250V 15A) Plug Type #57 (DENAN marking) | |
| 7801 |
16R0449 41V0479 52P7524 |
Ethernet Cable 6M Hardware Management Console to System Unit |
| 7802 |
05N5292 41V0143 52P7525 |
Ethernet Cable 15M Hardware Management Console to System Unit |
| 8133 |
43G0935 51G8610 |
RJ-45 to DB-25 Converter Cable |
| EN01 | 1m (3.3-ft), 10GbE'Net Cable SFP+ Act Twinax Copper | |
| EN02 | 3m (9.8-ft) 10GbE'Net Cable SFP+ Act Twinax Copper | |
| EN03 | 5m (16.4-ft) 10GbE'Net Cable SFP+ Act Twinax Copper | |
| 机壳 | ||
| 6238 | HIGH-END APPEARANCE SIDE COVERS | |
| 6250 | HIGH-END APPEARANCE FRONT DOOR | |
| 7840 | Side-by-Side for 1.8m Racks | |
| 其它 | ||
| 46K5179 | FSP cover plate | |
| 1104 |
39M5516 44E8889 44V3429 46C5381 46C5394 49Y9890 |
USB External Docking Station for Removable Disk Drive |
| 1106 |
46C5374 46C5375 |
USB 160 GB Removable Disk Drive |
| 1107 |
46C5379 46C5395 |
USB 500 GB Removable Disk Drive |
| 1120 | Decline Electronic Service Agent Install Indicator | |
| 1140 | Custom Service Specify, Rochester Minn, USA | |
| 1406 |
14F1553 39M5279 39Y5565 40K9772 |
200V 16A 4.3m (14-Ft) TL Line Cord |
| 1413 | 125V 4.3m (14-Ft) Line Cord | |
| 1414 |
39M5115 41V1961 86G7878 |
200V 6-Ft Locking Line Cord |
| 1415 |
41V1966 73F4931 |
200V 1.8m (6-Ft) Watertight Line Cord |
| 1416 | 200V 14-Ft Locking Line Cord | |
| 1417 | 200V 4.3m (14-Ft) Watertight Line Cord | |
| 1418 |
14F1557 39M5291 40K9770 |
4.3m 200V/16A Power Cord S. Africa |
| 1419 |
14F1561 39M5311 40K9771 |
4.3m 200V/16A Power Cord Israel |
| 1420 |
14F1554 39M5383 40K9766 |
4.3m 200V/16A Power Cord EU/Asia |
| 1421 |
14F1555 36L8823 39M5323 40K9769 |
4.3m 200V/16A Power Cord CH/DK |
| 1424 |
11F0114 11F0117 11F0117 41V2004 |
200V 6-Ft Locking Line Cord |
| 1425 |
07H6891 23R3230 46F4593 |
200V 6-Ft Wtrtght Line Cord |
| 1426 |
11F0113 11F0115 41V2003 |
200V 14-Ft Locking Line Cord |
| 1427 |
23R3231 46F4594 |
200V 14-Ft Wtrtght Line Cord |
| 1439 |
13F99809 39M5124 |
4.3m 200V/10A Power Cord EU/Asia |
| 1440 |
13F9998 39M5131 |
4.3m 200V/10A Pwr Cd Denmark |
| 1441 |
14F0016 39M5145 |
4.3m 200V/10A Pwr Cd S Afric |
| 1442 |
14F0052 39M5159 |
4.3m 200V/10A Pwr Cd Swiss |
| 1443 |
14F0034 39M5152 |
4.3m 200V/10A Pwr Cd UK |
| 1449 | 21H7693 | 4.3m 200V/32A Power Cord EU 1-PH |
| 1450 | 21H7691 | 4.3m 200V/16A Pwr Cd EU 2-PH |
| 1451 |
14F1547 39M5261 |
200V (6-Ft) 1.8m Line Cord |
| 1452 |
14F1548 39M5263 |
200V 14-Ft Line Cord |
| 1453 |
14F1549 39M5273 |
200V 6-Ft Locking Line Cord |
| 1454 |
14F1550 39M5275 |
200V 12A 14-Ft TL Line Cord |
| 1455 |
14F1551 39M5313 86F2645 |
200V 6-Ft Wtrtght Line Cord |
| 1456 |
14F1552 39M5315 86F2646 |
200V (14-Ft) 4.3m Watertight Line Cord |
| 1457 |
12J5120 39M5262 |
200V 6-Ft (1.8mUpper Line Cord |
| 1458 |
12J5119 39M5274 |
200V 6-Ft (1.8mUpper Locking Cord |
| 1459 |
93M5314 55H6644 |
200V 6-Ft Upper Wtrtght Cord |
| 1476 |
12J5988 39M5295 40K9767 |
4.3m/200V/12A Pwr Cd UK |
| 1477 | 4.3m 200V/16A Pwr Cd | |
| 1853 |
74Y5685 74Y5686 |
Operator Panel |
| 2145 | 21H8079 | Primary OS - IBM i |
| 2146 | 44H6111 | Primary OS - AIX |
| 2147 | Primary OS - Linux | |
| 3632 | Widescreen LCD Monitor | |
| 3635 |
04N7526 04N7527 04N7532 06P3812 13F9959 22P4525 22P4526 22P4530 22P4532 22P4534 22P4535 22P4536 31P9260 |
T210 Flat-Panel Monitor |
| 3637 |
04N7526 04N7527 04N7532 13F9959 31P7507 31P7509 31P7511 31P7513 31P7515 |
IBM T541H /L150p 15" TFT Color Monitor |
| 3639 |
13F9959 31P9575 31P9577 31P9584 31P9587 31P9590 73P0261 |
L180P TFT 17" Color Display |
| 3640 | L171P TFT 17" Black Display | |
| 3641 |
40K7317 40K5341 73P4360 |
T115 TFT 15" Color Display |
| 3642 | ThinkVision L191p Flat Panel Monitor | |
| 3644 | IBM T119 Flat Panel Monitor | |
| 3645 |
39Y9919 40k5342 |
IBM T117 Flat Panel Monitor |
| 4276 |
04N7533 09N3435 25R9043 |
VGA to DVI Connection Converter |
| 4650 | Rack Indicator-Not Factory Integrated | |
| 4651 | Rack Indicator, Rack #1 | |
| 4660 | Rack Indicator, Rack #10 | |
| 4661 | Rack Indicator, Rack #11 | |
| 4662 | Rack Indicator, Rack #12 | |
| 4663 | Rack Indicator, Rack #13 | |
| 4664 | Rack Indicator, Rack #14 | |
| 4665 | Rack Indicator, Rack #15 | |
| 4666 | Rack Indicator, Rack #16 | |
| 4891 | CBU SPECIFY | |
| 5000 | Software Preload Required | |
| 5001 | Customer Solution Center | |
| 5002 |
07H9163 07H9163 31H3140 31H3140 |
AS/400 CDSC - Rochester Mfg |
| 5524 | RFID TAGS FOR SERVERS, BLADES, BLADECENTERS, RACKS, AND HMCS | |
| 5550 | Sys Console On HMC | |
| 5553 | Sys Console-Ethernet No IOP | |
| 5597 |
44V5668 46K4625 46K6478 74Y1747 74Y1748 |
System CEC Enclosure with IBM BEZEL, I/O Backplane(44V5668), and System Midplane(PN:74Y5976), Mid-plane light pipe(46K4625). |
| 5598 |
44V5668 46K4625 46K6478 74Y1747 74Y1748 |
System CEC Enclosure with IBM BEZEL, I/O Backplane(44V5668), and System Midplane(PN:74Y5976), Mid-plane light pipe(46K4625). |
| 5786 | TotalStorage EXP24 Disk Dwr | |
| 5796 | PCI-DDR 12X Expansion Drawer | |
| 5802 | 12X I/O Drawer PCIe, SFF disk | |
| 5877 | 12X I/O Drawer PCIe, No Disk | |
| 5886 | EXP 12S Expansion Drawer | |
| 5887 | EXP24S SFF Gen2-bay Drawer | |
| 5959 | Full Width Quiet Touch Keyboard -- USB, Hungarian, #208 | |
| 5983 | USB Keybd-US English Euro | |
| 6068 | Opt Front Door for 1.8m Rack | |
| 6069 | Opt Front Door for 2.0m Rack | |
| 6246 | 1.8m Rack Trim Kit | |
| 6247 | 2.0m Rack Trim Kit | |
| 6248 |
12R8349 44V0103 |
1.8m Rack Acoustic Doors |
| 6249 | 2.0m Rack Acoustic Doors | |
| 6263 | 1.8m Rack Trim Kit | |
| 6272 | 2.0m Rack Trim Kit | |
| 6492 | 4.3m (14-Ft) 1PH/48-60A Pwr Cord | |
| 6577 | Power Cable - Drawer to IBM PDU, 200-240V/10A | |
| 6580 | 41V0489 | Optional Rack Security Kit |
| 7118 | Environmental Monitoring Probe | |
| 7204 | Quantity 150 of #2124 | |
| 7205 | Quantity 150 of #2125 | |
| 7206 | Quantity 150 of #2126 | |
| 7207 | Quantity 150 of #2127 | |
| 7208 | Quantity 150 of #2128 | |
| 7213 | Quantity 150 of #2138 | |
| 7305 | SDI Software Pre-Install Indicator | |
| 7314 | Dual 5796 Unit Enclosure | |
| 7780 | 2.0m Rack Side Attach Kit | |
| 7942 | Advanced POWER Virtualization | |
| 7995 | PowerVM - Enterprise Edition | |
| 8018 | Advanced POWER Virtualization Carry Over Indicator | |
| 8030 | Advanced POWER Virtualization Carry Over Indicator | |
| 8143 | Linux Software Preinstall | |
| 8144 | Linux Software Preinstall (SDIs) | |
| 8453 | Base Customer Spec Plcmnt | |
| 9300 | Language Group Specify - US English | |
| 9359 | specify mode-1 1(1)5901/5278 for EXP24S #5887 | |
| 9360 | Specify mode-1 1(2)5901/5278 for EXP24S #5887 | |
| 9361 | Specify mode-2 1(2)5901/5278 for EXP24S #5887 | |
| 9365 | Specify mode-4 1(4)5901/5278 for EXP24S #5887 | |
| 9366 | -Specify mode-2 1(4)5901/5278 for EXP24S #5887 | |
| 9367 | -Specify mode-1 1(2)5903/5805 for EXP24S #5887 | |
| 9368 | Specify mode-2 1(4)5903/5805 for EXP24S #5887 | |
| 9382 | Specify mode-1 1(1)5904/6/8 for EXP24S #5887 | |
| 9383 | Specify mode-1 1(2) 5904/6/8 for EXP24S #5887 | |
| 9384 | Specify mode-1 & CEC SAS port for EXP24 #5887 | |
| 9440 | New AIX License Core Counter | |
| 9441 | New IBM i License Core Counter | |
| 9442 | New Red Hat License Core Counter | |
| 9443 | New SUSE License Core Counter | |
| 9444 | Other AIX License Core Counter | |
| 9445 | Other Linux License Core Counter | |
| 9446 | 3rd Party Linux Core Counter | |
| 9447 | VIOS Core Counter | |
| 9461 | Month Indicator | |
| 9462 | Day Indicator | |
| 9463 | Hour Indicator | |
| 9464 | Minute Indicator | |
| 9465 | Qty Indicator | |
| 9466 | Countable Member Indicator | |
| 9570 |
1039570 1381584 |
Reserved Rack Space Indicator - 4U |
| ELPM | Trial PowerVM Live Partition Mobility |
