外形 |
1U 机架 |
|
处理器 |
最多两个英特尔®至强® E5-2600 v4 处理器系列，每个处理器最多22 个内核，每个处理器最高55MB 缓存 |
|
内存 |
容量高达1.5TB—— 24个内存插槽，搭配单条最高2400MHz 的64GB TruDDR4 内存LRDIMM（RDIMM/LRDIMM） |
|
磁盘托架 |
最多10 个前置和两个后置2.5 英寸HDD 或SSD，或最多四个3.5 英寸HDD |
|
最大内部存储容量 |
最大46TB |
|
RAID支持 |
12Gbps 专用RAID 插槽，支持硬件RAID 0、1、10；可选RAID 5、50、6、60 |
|
电源 |
标配1 颗热插拔电源，可选1+1 冗余550W AC、750W AC、900W AC、1500W AC、900W DC 80 PLUS 铂金认证和750W AC 80 PLUS 钛金认证电源（因机型而异） |
|
可热插拔组件 |
电源、风扇模块和HDD/SSD |
|
网络接口 |
标配1 个IMM 和4 个1GbE 接口；可选10/40GbE ML2 或PCIe 适配器；内置可信平台模块（Trusted Platform Module） |
|
扩展插槽 |
1-3 个PCIe 3.0 插槽和1 个专用RAID 插槽 |
|
USB端口/VGA端口 |
最多3 个USB 2.0 前置、2 个USB 3.0 后置、1 个USB 2.0 内置/1 个前置（可选）/1 个后置端口 |
|
能效 |
80 PLUS®、ENERGY STAR®（因机型而异）；工作温度最高为40℃； 2 个风扇区，最多配8个风扇 |
|
系统管理 |
Lenovo XClarity Administrator（具有移动选项）； Lenovo XClarity Pro 软件包；Lenovo XClarity Energy Manager；IMM2.1；一个IMM 专用端口和一个共享端口；远程再现（remotepresence）特性可选 |
|
支持的操作系统 |
Microsoft Windows Server、Red Hat Enterprise Linux、SUSE Linux Enterprise Server、VMware vSphere——（USB 密钥或SD 卡适配器可选） |
MT 5463
CPU
Description/Part number/Feature codes
Intel Xeon Processor E5-2603 v3 6C 1.6GHz 15MB 1600MHz 85W 00KA070 A5BF / A5BV
Intel Xeon Processor E5-2608L v3 6C 2.0GHz 15MB 1866MHz 52W 00MU566 ASL6 / ASLF
Intel Xeon Processor E5-2609 v3 6C 1.9GHz 15MB 1600MHz 85W 00KA071 A5BG / A5BW
Intel Xeon Processor E5-2618L v3 8C 2.3GHz 20MB 1866MHz 75W 00MU567 ASL7 / ASLG
Intel Xeon Processor E5-2620 v3 6C 2.4GHz 15MB 1866MHz 85W 00KA067 A5BC / A5BS
Intel Xeon Processor E5-2623 v3 4C 3.0GHz 10MB 1866MHz 105W 00MU407 ASCT / ASD4
Intel Xeon Processor E5-2628L v3 10C 2.0GHz 25MB 1866MHz 75W 00MU568 ASL8 / ASLH
Intel Xeon Processor E5-2630 v3 8C 2.4GHz 20MB 1866MHz 85W 00KA068 A5BD / A5BT
Intel Xeon Processor E5-2630L v3 8C 1.8GHz 20MB 1866MHz 55W 00KA077 A5BN / A5C2
Intel Xeon Processor E5-2637 v3 4C 3.5GHz 15MB 2133MHz 135W 00MU408 ASCU / ASD5
Intel Xeon Processor E5-2640 v3 8C 2.6GHz 20MB 1866MHz 90W 00KA069 A5BE / A5BU
Intel Xeon Processor E5-2643 v3 6C 3.4GHz 20MB 2133MHz 135W 00MU409 ASCV / ASD6
Intel Xeon Processor E5-2648L v3 12C 1.8GHz 30MB 2133MHz 75W 00MU569 ASL9 / ASLJ
Intel Xeon Processor E5-2650 v3 10C 2.3GHz 25MB 2133MHz 105W 00KA072 A5BH / A5BX
Intel Xeon Processor E5-2650L v3 12C 1.8GHz 30MB 2133MHz 65W 00MU406 ASCS / ASD3
Intel Xeon Processor E5-2658 v3 12C 2.2GHz 30MB 2133MHz 105W 00MU570 ASLA / ASLK
Intel Xeon Processor E5-2660 v3 10C 2.6GHz 25MB 2133MHz 105W 00MU400 ASCL / ASCX
Intel Xeon Processor E5-2667 v3 8C 3.2GHz 20MB 2133MHz 135W 00MU410 ASCW / ASD7
Intel Xeon Processor E5-2670 v3 12C 2.3GHz 30MB 2133MHz 120W 00KA074 A5BK / A5BZ
Intel Xeon Processor E5-2680 v3 12C 2.5GHz 30MB 2133MHz 120W 00KA075 A5BL / A5C0
Intel Xeon Processor E5-2683 v3 14C 2.0GHz 35MB 2133MHz 120W 00MU401 ASCM / ASCY
Intel Xeon Processor E5-2685 v3 12C 2.6GHz 30MB 2133MHz 120W 00MU402 ASCN / ASCZ
Intel Xeon Processor E5-2690 v3 12C 2.6GHz 30MB 2133MHz 135W 00KA076 A5BM / A5C1
Intel Xeon Processor E5-2695 v3 14C 2.3GHz 35MB 2133MHz 120W 00MU403 ASCP / ASD0
Intel Xeon Processor E5-2697 v3 14C 2.6GHz 35MB 2133MHz 145W 00MU404 ASCQ / ASD1
Intel Xeon Processor E5-2698 v3 16C 2.3GHz 40MB 2133MHz 135W 00MU405 ASCR / ASD2
Intel Xeon Processor E5-2699 v3 18C 2.3GHz 45MB 2133MHz 145W 00KF584 ARZ8 / ARZ9
Description/Part number/Feature code/Maximum supported
RDIMMs - 2133 MHz
4GB TruDDR4 Memory (1Rx8, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 46W0784 A5B6 12 / 24
8GB TruDDR4 Memory (1Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 46W0788 A5B5 12 / 24
8GB TruDDR4 Memory (2Rx8, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 46W0792 A5B8 12 / 24
16GB TruDDR4 Memory (2Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 46W0796 A5B7 12 / 24
32GB TruDDR4 Memory (2Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 95Y4808 A5UJ 12 / 24
LRDIMMs - 2133 MHz
32GB TruDDR4 Memory (4Rx4, 1.2V) PC417000 CL15 2133MHz LP LRDIMM 46W0800 A5B9 12 / 24
64GB TruDDR4 Memory (4Rx4,1.2V) PC4-17000 CL15 2133MHz LP LRDIMM 95Y4812 A5UK 12 / 24
MT 8869
CPU
Intel Xeon Processor E5-2600 v4 product family
Intel Xeon Processor E5-2603 v4 6C 1.7GHz 15MB Cache 1866MHz 85W 00YE893 ATLT / ATMH
Intel Xeon Processor E5-2608L v4 8C 1.6GHz 20MB Cache 1866MHz 50W 00YJ695 ATMC / ATN3
Intel Xeon Processor E5-2609 v4 8C 1.7GHz 20MB Cache 1866MHz 85W 00YE894 ATLU / ATMJ
Intel Xeon Processor E5-2618L v4 10C 2.2GHz 25MB Cache 2133MHz 75W 00YJ696 ATMD / ATN4
Intel Xeon Processor E5-2620 v4 8C 2.1GHz 20MB Cache 2133MHz 85W 00YE895 ATLV / ATMK
Intel Xeon Processor E5-2623 v4 4C 2.6GHz 10MB Cache 2133MHz 85W 00YJ694 ATMB / ATN2
Intel Xeon Processor E5-2628L v4 12C 1.9GHz 30MB Cache 2133MHz 75W 00YJ697 ATME / ATN5
Intel Xeon Processor E5-2630 v4 10C 2.2GHz 25MB Cache 2133MHz 85W 00YE896 ATLW / ATML
Intel Xeon Processor E5-2630L v4 10C 1.8GHz 25MB Cache 2133MHz 55W 00YJ693 ATMA / ATN1
Intel Xeon Processor E5-2637 v4 4C 3.5GHz 15MB Cache 2400MHz 135W 00YJ692 ATM9 / ATN0
Intel Xeon Processor E5-2640 v4 10C 2.4GHz 25MB Cache 2133MHz 90W 00YE897 ATLX / ATMM
Intel Xeon Processor E5-2643 v4 6C 3.4GHz 20MB Cache 2400MHz 135W 00YJ691 ATM8 / ATMZ
Intel Xeon Processor E5-2648L v4 14C 1.8GHz 35MB Cache 2400MHz 75W 00YJ698 ATMF / ATN6
Intel Xeon Processor E5-2650 v4 12C 2.2GHz 30MB Cache 2400MHz 105W 00YE898 ATLY / ATMN
Intel Xeon Processor E5-2650L v4 14C 1.7GHz 35MB Cache 2400MHz 65W 00YJ690 ATM7 / ATMY
Intel Xeon Processor E5-2658 v4 14C 2.3GHz 35MB Cache 2400MHz 105W 00YJ699 ATMG / ATN7
Intel Xeon Processor E5-2660 v4 14C 2.0GHz 35MB Cache 2400MHz 105W 00YJ101 ATM1 / ATMR
Intel Xeon Processor E5-2667 v4 8C 3.2GHz 25MB Cache 2400MHz 135W 00YJ102 ATM2 / ATMS
Intel Xeon Processor E5-2680 v4 14C 2.4GHz 35MB Cache 2400MHz 120W 00YJ686 ATM3 / ATMU
Intel Xeon Processor E5-2683 v4 16C 2.1GHz 40MB Cache 2400MHz 120W 00YJ689 ATM6 / ATMX
Intel Xeon Processor E5-2690 v4 14C 2.6GHz 35MB Cache 2400MHz 135W 00YE899 ATLZ / ATMP
Intel Xeon Processor E5-2695 v4 18C 2.1GHz 45MB Cache 2400MHz 120W 00YJ688 ATM5 / ATMW
Intel Xeon Processor E5-2697 v4 18C 2.3GHz 45MB Cache 2400MHz 145W 00YJ103 ATLS / ATMT
Intel Xeon Processor E5-2697A v4 16C 2.6GHz 40MB Cache 2400MHz 145W 01GT187 AUDX / AUDZ
Intel Xeon Processor E5-2698 v4 20C 2.2GHz 50MB Cache 2400MHz 135W 00YJ687 ATM4 / ATMV
Intel Xeon Processor E5-2699 v4 22C 2.2GHz 55MB Cache 2400MHz 145W 00YJ100 ATM0 / ATMQ
Intel Xeon Processor E5-2699R v4 22C 2.2GHz 55MB Cache 2400MHz 145W 01GT324 AVH8 / AVHG
Intel Xeon Processor E5-2699A v4 22C 2.4GHz 55MB Cache 2400MHz 145W 01GT325 AVH9 / AVHH
内存
RDIMMs - 2400 MHz
8GB TruDDR4 Memory (1Rx4, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 46W0821 ATC8 12 / 24
8GB TruDDR4 Memory (2Rx8, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 46W0825 ATC9 12 / 24
16GB TruDDR4 Memory (2Rx4, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 46W0829 ATCA 12 / 24
16GB TruDDR4 Memory (2Rx8, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 01KN301 AVP0 12 / 24
32GB TruDDR4 Memory (2Rx4, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 46W0833 ATCB 12 / 24
LRDIMMs - 2400 MHz
64GB TruDDR4 Memory (4Rx4, 1.2V) PC4-19200 PC4 2400MHz LP LRDIMM 46W0841 ATGG 12 / 24
Base drive kits
System x3550 M5 4x 2.5" HS HDD Kit None A59W 1
System x3550 M5 4x 3.5" HS HDD Kit None A5A4 1
System x3550 M5 10x 2.5" HS HDD Kit None A5A0 1
System x3550 M5 4x 2.5" SS HDD Kit, Non-Raid None A59Y 1
System x3550 M5 4x 3.5" SS HDD Kit, Non-Raid None A5A5 1
System x3550 M5 4x 2.5" SS HDD Kit, HW RAID None A5A6 1
System x3550 M5 4x 3.5" SS HDD Kit, HW RAID None A5A8 1
Upgrade drive kits (require the base drive kit)
System x3550 M5 2x 2.5" HS HDD Rear Kit 00KA058 A5A2 1
System x3550 M5 4x 2.5" HS HDD Kit PLUS 00KA055 A59X 1
System x3550 M5 4x 2.5" SS HDD Kit PLUS, Non-Raid 00KA056 A59Z 1
System x3550 M5 4x 2.5" SS HDD Kit PLUS, HW RAID 00KA060 A5A7 1
阵列卡
Description/Part number/Feature code/Maximum supported/I/O slots supported
12 Gb SAS/SATA controllers
ServeRAID M5210 SAS/SATA Controller 46C9110 A3YZ 1 4
ServeRAID M1215 SAS/SATA Controller 46C9114 A45W 1 4
N2215 SAS/SATA HBA 47C8675 A3YY 1 4
Hardware upgrades for the M5210 (per one controller)
ServeRAID M5200 Series 1GB Cache/RAID 5 Upgrade 47C8656 A3Z0 1 -
ServeRAID M5200 Series 1GB Flash/RAID 5 Upgrade 47C8660 A3Z1 1 -
ServeRAID M5200 Series 2GB Flash/RAID 5 Upgrade 47C8664 A3Z2 1 -
ServeRAID M5200 Series 4GB Flash/RAID 5 Upgrade 47C8668 A3Z3 1 -
Features on Demand upgrades for the M5210 (per one server)**
ServeRAID M5200 Series Zero Cache/RAID 5 Upgrade 47C8708 A3Z6 1 -
ServeRAID M5200 Series RAID 6 Upgrade 47C8706 A3Z5 1* -
ServeRAID M5200 Series Performance Accelerator 47C8710 A3Z7 1* -
ServeRAID M5200 Series SSD Caching Enabler 47C8712 A3Z8 1* -
Features on Demand upgrades for the M1215 (per one server)**
ServeRAID M1200 Zero Cache/RAID 5 Upgrade 00AE930 A5H5 1 -
硬盘
Description/Part number/Feature code/Maximum supported
2.5-inch hot-swap HDDs - 12 Gbps SAS
300GB 10K 12Gbps SAS 2.5" G3HS HDD 00WG685 AT89 12
300GB 15K 12Gbps SAS 2.5" G3HS HDD 00WG660 AT84 12
600GB 10K 12Gbps SAS 2.5" G3HS HDD 00WG690 AT8A 12
600GB 15K 12Gbps SAS 2.5" G3HS HDD 00WG665 AT85 12
900GB 10K 12Gbps SAS 2.5" G3HS HDD 00WG695 AT8B 12
1.2TB 10K 12Gbps SAS 2.5" G3HS HDD 00WG700 AT8C 12
1.8TB 10K 12Gbps SAS 2.5" G3HS 512e HDD 00NA271 ASBM 12
2.5-inch hot-swap HDDs - 12 Gbps NL SAS
1TB 7.2K 12Gbps NL SAS 2.5" G3HS HDD 00NA491 AT7Z 12
2TB 7.2K 12Gbps NL SAS 2.5" G3HS HDD 00NA496 AT80 12
2.5-inch hot-swap HDDs - 6 Gbps NL SATA
1TB 7.2K 6Gbps NL SATA 2.5" G3HS HDD 00AJ141 A4TX 12
2TB 7.2K 6Gbps NL SATA 2.5'' G3HS 512e HDD 00NA526 AT81 12
2.5-inch hot-swap SEDs - 12 Gbps SAS
300GB 10K 12Gbps SAS 2.5" G3HS SED 00WG705 AT8D 12
600GB 10K 12Gbps SAS 2.5" G3HS SED 00WG710 AT8E 12
900GB 10K 12Gbps SAS 2.5" G3HS SED 00WG715 AT8F 12
1.2TB 10K 12Gbps SAS 2.5" G3HS SED 00WG720 AT8G 12
2.5-inch simple-swap HDDs - 6 Gbps NL SATA
1TB 7.2K 6Gbps NL SATA 2.5" G3SS HDD 00NA622 ASLD 8
3.5-inch hot-swap HDDs - 12Gbps SAS
300GB 15K 12Gbps SAS 3.5" G2HS HDD 00WG675 AT87 4
600GB 15K 12Gbps SAS 3.5" G2HS HDD 00WG680 AT88 4
3.5-inch hot-swap HDDs - 12 Gbps NL SAS
1TB 7.2K 12Gbps NL SAS 3.5" G2HS HDD 00YL702 ATYM 4
2TB 7.2K 12Gbps NL SAS 3.5" G2HS HDD 00YK000 ATYL 4
2TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 00FN188 A5VP 4
4TB 7.2K 12Gbps NL SAS 3.5" G2HS HDD 00YK005 ATYN 4
6TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 00FN228 A5VR 4
8TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 00WH121 ATRS 4
10TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 00YK336 AU7R 4
3.5-inch hot-swap HDDs - 6 Gbps NL SATA
1TB 7.2K 6Gbps NL SATA 3.5" G2HS HDD 81Y9790 A22P 4
2TB 7.2K 6Gbps NL SATA 3.5" G2HS HDD 81Y9794 A22T 4
6TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 00FN173 A5VM 4
8TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 00WH126 ATRT 4
10TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 00YK341 AU7S 4
3.5-inch simple-swap HDDs - 6 Gbps NL SATA
1TB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 81Y9806 A22X 4
2TB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 81Y9810 A22W 4
Description/Part number/Feature code/Maximum supported
Ultraslim 9.5mm SATA DVD-ROM 00AM066 A5KG 1
Ultraslim 9.5mm SATA Multi Burner 00AM067 A5KH 1
Ultraslim 9.5mm SATA DVD-ROM 00AM066 A5KG 1
Ultraslim 9.5mm SATA Multi Burner 00AM067 A5KH 1
PCI riser card
Description/Part number/Feature code/Maximum supported
Riser 1 (supplies slots 1)
System x3550 M5 PCIe Riser 1 (1x LP x16 CPU0) 00KA061 A5AG 1
System x3550 M5 PCIe Riser 1 (1x ML2 x16 CPU0) 00KA063 A5AH 1
Riser 2 (supplies slots 2 and 3)
System x3550 M5 PCIe Riser 2, 1 CPU (2xLP, LP x8 CPU0 + LP x8 CPU0) 00KA062 A5AC 1
System x3550 M5 PCIe Riser 2, 1-2 CPU (FHHL x16 CPU1 + LP x16 CPU0) None* A5AD 1
System x3550 M5 PCIe Riser 2, 1 CPU (FHHL x8 CPU0 +LP x8 CPU0) None* A5AE 1
System x3550 M5 PCIe Riser 2, 1-2 CPU (LP x16 CPU1 + LP x16 CPU0) 00KA066 A5AF 1
网卡
Description/Part number/Feature code/Maximum supported/I/O slots supported
100 Gb Ethernet - PCIe
Mellanox ConnectX-4 2x100GbE/EDR IB QSFP28 VPI Adapter 00MM960 ATRP 3^ 1, 2, 3
40 Gb Ethernet - ML2
Mellanox ConnectX-3 Pro ML2 2x40GbE/FDR VPI Adapter 00FP650 A5RK 1* 1
40 Gb Ethernet - PCIe
Mellanox ConnectX-4 Lx 1x40GbE QSFP+ Adapter 00MM950 ATRN 3* 1, 2, 3
Mellanox ConnectX-3 2x40GbE / FDR IB VPI Adapter 00D9550 A3PN 3* 1, 2, 3
25 Gb Ethernet - ML2
Mellanox ConnectX-4 Lx ML2 1x25GbE SFP28 Adapter 00MN990 ATZR 1# 1
10 Gb Ethernet - ML2
Broadcom NetXtreme II ML2 Dual Port 10GbaseT 00D2026 A40S 1 1
Broadcom NetXtreme II ML2 Dual Port 10GbE SFP+ 00D2028 A40T 1* 1
Emulex VFA5 ML2 FCoE/iSCSI License (FoD)
(Upgrade for 00D1996 - one per adapter)
00D8544 A4NZ 1 -
Intel X540 ML2 Dual Port 10GbaseT Adapter 00D1994 A40P 1 1
Intel X710-DA2 ML2 2x10GbE SFP+ Adapter 00JY940 ATRH 1* 1
25 Gb Ethernet - PCIe
Mellanox ConnectX-4 Lx 2x25GbE SFP28 Adapter 01GR250 AUAJ 3# 1, 2, 3
10 Gb Ethernet - PCIe
Broadcom NetXtreme 2x10GbE BaseT Adapter 44T1370 A5GZ 3 1, 2, 3
Broadcom NetXtreme Dual Port 10GbE SFP+ Adapter 94Y5180 A4Z6 3* 1, 2, 3
Emulex VFA5 2x10 GbE SFP+ PCIe Adapter 00JY820 A5UT 3* 1, 2, 3
Emulex VFA5.2 2x10 GbE SFP+ PCIe Adapter 00AG570 AT7S 3* 1, 2, 3
Emulex VFA5 FCoE/iSCSI SW for PCIe Adapter (FoD)
(Upgrade for 00JY820 and 00AG570 - one per adapter)
00JY824 A5UV 3 -
Emulex VFA5.2 2x10 GbE SFP+ Adapter and FCoE/iSCSI SW 00AG580 AT7T 3* 1, 2, 3
Intel X520 Dual Port 10GbE SFP+ Adapter 49Y7960 A2EC 3* 1, 2, 3
Intel X540-T2 Dual Port 10GBaseT Adapter 49Y7970 A2ED 3 1, 2, 3
Intel X550-T2 Dual Port 10GBase-T Adapter 00MM860 ATPX 3 1, 2, 3
Intel X710-DA2 2x10GbE SFP+ Adapter 01DA900 AU2Y 3* 1, 2, 3
Mellanox ConnectX-3 2x10GbE Adapter 00D9690 A3PM 3* 1, 2, 3
1 Gb Ethernet - ML2
Intel I350-T4 ML2 Quad Port GbE Adapter 00D1998 A40R 1 1
1 Gb Ethernet - PCIe
Broadcom NetXtreme I Dual Port GbE Adapter 90Y9370 A2V4 3 1, 2, 3
Broadcom NetXtreme I Quad Port GbE Adapter 90Y9352 A2V3 3 1, 2, 3
Intel I350-F1 1xGbE Fiber Adapter 00AG500 A56K 3 1, 2, 3
Intel I350-T2 2xGbE BaseT Adapter 00AG510 A56L 3 1, 2, 3
Intel I350-T4 4xGbE BaseT Adapter 00AG520 A56M 3 1, 2, 3
40 GbE QSFP+ transceivers and DAC cables for 40 GbE QSFP+ adapters
Lenovo 40GBASE-SR4 QSFP+ Transceiver 49Y7884 A1DR Port qty** -
Lenovo 1m Passive QSFP+ DAC Cable 49Y7890 A1DP Port qty** -
Lenovo 3m Passive QSFP+ DAC Cable 49Y7891 A1DQ Port qty** -
10 GbE SFP+ transceivers and DAC cables for 10 GbE SFP+ adapters
Lenovo 10GBASE-SR SFP+ Transceiver 46C3447 5053 Port qty** -
Brocade 10Gb SFP+ SR Optical Transceiver 49Y4216 0069 Port qty** -
QLogic 10Gb SFP+ SR Optical Transceiver 49Y4218 0064 Port qty** -
Lenovo 0.5m Passive SFP+ DAC Cable 00D6288 A3RG Port qty** -
Lenovo 1m Passive SFP+ DAC Cable 90Y9427 A1PH Port qty** -
Lenovo 1.5m Passive SFP+ DAC Cable 00AY764 A51N Port qty** -
Lenovo 2m Passive SFP+ DAC Cable 00AY765 A51P Port qty** -
Lenovo 3m Passive SFP+ DAC Cable 90Y9430 A1PJ Port qty** -
Lenovo 5m Passive SFP+ DAC Cable 90Y9433 A1PK Port qty** -
Lenovo 7m Passive SFP+ DAC Cable 00D6151 A3RH Port qty** -
SAS RAID adapters and HBAs
Description/Part number/Feature code/Maximum supported/I/O slots supported
12 Gbps SAS RAID adapters - PCIe
ServeRAID M5225-2GB SAS/SATA Controller 00AE938 A5ND 3 1, 2, 3
Feature on Demand (FoD) upgrades for the M5225 (one per server)*
ServeRAID M5200 Series RAID 6 Upgrade 47C8706 A3Z5 1* -
ServeRAID M5200 Series Performance Accelerator 47C8710 A3Z7 1* -
ServeRAID M5200 Series SSD Caching Enabler 47C8712 A3Z8 1* -
12 Gbps SAS HBAs - PCIe
N2225 SAS/SATA HBA 00AE912 A5M0 3 1, 2, 3
N2226 SAS/SATA HBA 00AE916 A5M1 1** 2
光纤卡
Description/Part number/Feature code/Maximum supported/I/O slots supported
16 Gb Fibre Channel - PCIe
Emulex 16Gb Gen6 FC Single-port HBA 01CV830 ATZU 3 1, 2, 3
Emulex 16Gb Gen6 FC Dual-port HBA 01CV840 ATZV 3 1, 2, 3
Emulex 16Gb FC Single-port HBA 81Y1655 A2W5 2 2, 3
Emulex 16Gb FC Dual-port HBA 81Y1662 A2W6 2 2, 3
QLogic 16Gb Enhanced Gen5 FC Single-port HBA 01CV750 ATZB 3 1, 2, 3
QLogic 16Gb Enhanced Gen5 FC Dual-port HBA 01CV760 ATZC 3 1, 2, 3
QLogic 16Gb FC Single-port HBA 00Y3337 A3KW 3 1, 2, 3
QLogic 16Gb FC Dual-port HBA 00Y3341 A3KX 3 1, 2, 3
8 Gb Fibre Channel - PCIe
Emulex 8Gb FC Single-port HBA 42D0485 3580 3 1, 2, 3
Emulex 8Gb FC Dual-port HBA 42D0494 3581 3 1, 2, 3
QLogic 8Gb FC Single-port HBA 42D0501 3578 3 1, 2, 3
QLogic 8Gb FC Dual-port HBA 42D0510 3579 3 1, 2, 3
GPU
Description/Part number/Feature code/Maximum supported/I/O slots supported
NVIDIA Quadro K420 00YL370 ASPN 1 2
NVIDIA Quadro K620 00YL371 ASPP 1 2
电源
Description/Part number/Feature code/Maximum supported
System x 550W High Efficiency Platinum AC Power Supply 00KA094 A5AX 2
System x 750W High Efficiency Platinum AC Power Supply 00KA096 A5AY 2
System x 750W High Efficiency Titanium AC Power Supply (200-240V) 00KA097 A5AZ 2
System x 900W High Efficiency Platinum AC Power Supply 00KA098 A5B0 2
System x 900W High Efficiency -48 V DC Power Supply 00MV212 ASPR 2
System x 1500W High Efficiency Platinum AC Power Supply (200-240V) 00MV211 ASPQ 2
