IBM DS4700
| 整机信息 | |
| 名称 | IBM TotalStorage DS4700 Express |
| 型号 | 1814-70A/1814-70S/1814-72A |
| 机架空间 | 3U |
| 控制器信息 | 双主4GB RAID控制器 |
| 整机控制器缓存 | 2GB 到 4GB |
| 控制器是否有电池 | 是 |
| 接口 | 4个主机端口 - 标配光纤通道 （FC） 交换和 FC 仲裁环路 （FC-AL），自动检测 1GBps/2GBps/4GBps；4个驱动器端口 - 标配光纤通道 （FC） 交换和 FC 仲裁环路 （FC-AL），自动-检测 1GBps/2GBps/4GBps |
| 硬盘插槽数量 | 112 |
| 支持的硬盘 | 支持 4GBps FC：15k - 450GB、300GB、146.8GB、73.4GB、36.4GB、E-DDM；支持 4GBps SATA：7.2K 500GB/750GB 和 1TB E-DDM 磁盘驱动器 |
| 支持Raid类型 | 0, 1, 3, 5, 6, 10 |
| 发布日期 | |
| 下架日期 | 39824 |
| 存储分区 | 4、8、16 或 64个存储分区 |
| 可用性 | 容灾、RAID、冗余电源/风扇、热插拔驱动器、 单/双控制器、并行微码更新功能、双路径驱动器。 |
| SAN支持 | 支持的 IBM FC 交换机和导向器（产品编号 2005、2006、2109、2026、2027、2031、2032、2034、2042、2054、2061 和 2062 以及 IBM BladeCenter®） |
| 其他特性 | |
| 产品尺寸 | 高 130.3毫米（5.13英寸）、宽 447.0毫米（17.6英寸）、深 563.8毫米（22.2英寸） |
| 产品重量 | 29.03公斤 (64磅)- 39.92公斤 (88磅). |
| 保修 | 3 年部件和服务保修，9x5 下一工作日处理，可升级为全天候 4 小时响应· |
| 管理软件 | IBM System Storage DS4000 Storage Manager 版本 10.10 |
| 存储扩展柜 |
| 配件信息 | ||
| FC号 | PN号 | 描述 |
| 硬盘 | ||
| 4610 |
39M4554 39M4557 39M4575 |
500GB/7.2K SATA E-DDM (Withdrawn) |
| 4615 |
43W9714 43W9715 43W9720 |
750GB/7.2K SATA II E-DDM (Withdrawn) |
| 4618 |
44X2458 44X2459 |
1TB/7.2K SATA II E-DDM (Req fw >= 06.23.05.0) |
| 4620 | 59Y5536 | 2TB/7.2K SATA II E-DDM |
| 5221 |
39M4586 42D0386 |
2Gbps FC, 73.4GB/10K E-DDM (Withdrawn) |
| 5222 |
39M4590 42D0369 |
2Gbps FC, 146.8GB/10K E-DDM (Withdrawn) |
| 5223 |
39M4594 42D0370 |
2Gbps FC, 300GB/10K E-DDM (Withdrawn) |
| 5231 |
40K6800 42D0371 |
2Gbps FC, 36.4GB/15K E-DDM (Withdrawn) |
| 5232 |
40K6804 42D0372 |
2Gbps FC, 73.4GB/15K E-DDM (Withdrawn) |
| 5233 |
40K6808 42D0373 |
2Gbps FC, 146.8GB/15K E-DDM (Withdrawn) |
| 5412 |
40K6812 40K6815 |
4GBps FC, 36.4GB/15K E-DDM (Withdrawn) |
| 5413 |
40K6816 40K6819 |
4GBps FC, 73.4GB/15K E-DDM (Withdrawn) |
| 5414 |
40K6820 40K6823 |
4GBps FC, 146.8GB/15K E-DDM (Withdrawn) |
| 5415 |
42D0410 42D0413 42D0417 41Y8405 41Y8439 |
4GBps FC, 300GB/15K E-DDM |
| 5416 |
44X2450 44X2451 |
4GBps FC, 450GB/15K E-DDM |
| 5417 |
59Y5460 59Y5336 |
4GBps FC, 600GB/15K E-DDM |
| 适配卡 | ||
| 2105 | 39M5894 | DS4000 4Gbps Single-Port FC PCI-X cchba |
| 2106 | 39M5895 | DS4000 4Gbps Dual-Port FC PCI-X cchba |
| 电源 | ||
| 41Y5155 | AC power supply and fan unit FRU, 600 W (models that are not NEBs Level 3/Telco compliant) | |
| 42D3290 | DC power supply and fan unit FRU | |
|
42D3346 42D3314 |
AC power supply and fan unit FRU, 600 W (models that are NEBs Level 3/Telco compliant) | |
| 电池 | ||
| 41Y0679 | Battery, Cache | |
| 许可协议 | ||
| 2 | Incomplete System Unit-AAP | |
| 7301 | DS4500/4800 FlashCopy Activation(Withdraw) | |
| 7304 | DS4500/4800 Flash/Volume Copy Activation(Withdraw) | |
| 7305 | DS4500/4800 Enhanced Remote Mirror Activation(Withdraw) | |
| 7306 | DS4500/4800 FC/SATA Enhanced Intermix Activation(Withdraw) | |
| 7382 | 41Y5222 | DS4700 1-3 Storage Exps Attachment |
| 7383 | DS4700 4-6 Storage Exps Attachment | |
| 7700 | DS4700/4800 Windows Host Kit | |
| 7701 | 24P8068 | DS4300/4700/4800 Linux/Intel Host Kit (Withdrawn) |
| 7702 | 24P8069 | DS4300/4700/4800 Novell Network Host Kit (Withdrawn) |
| 7703 | 24P8070 | DS4300/4800 VMware Host Kit (Withdrawn)/DS4700 Vmware ESX Host Kit |
| 7711 | 24P8072 | DS4300/4800 AIX Host Kit (Withdrawn)/DS4700 AIX/VIOS Host Kit |
| 7712 | 24P8073 | DS4300/4800 Sun Host Kit (Withdrawn)/DS4700 SUN Host Kit |
| 7713 | 24P8074 | DS4300/4800 HP-UX Host Kit (Withdrawn) |
| 7714 | 25R0091 | DS4300/4800 Linux on Power Host Kit (Withdrawn)/DS4700 Linux on Power Host Kit |
| 8850 | DS4700 2 Storage Partitions Activation | |
| 8851 | DS4700 4 Storage Partitions Activation | |
| 8852 | DS4700 8 Storage Partitions Activation | |
| 8853 | DS4700 16 Storage Partitions Activation | |
| 8854 | DS4700 64 Storage Partitions Activation | |
| 8855 | DS4700 32 Storage Partitions Activation | |
| 8859 | DS4700 128 Storage Partitions Activation | |
| 控制器 | ||
|
39M5896 44X2423 |
DS4700 CONTROLLER Model 70, 1GB cache without Battery for 70A. | |
|
41Y0676 44X2426 |
DS4700 CONTROLLER Model 72, 2GB cache without Battery for 72A. | |
| 光纤模块 | ||
| 2410 |
26K7941 22R6443 77P2964 |
SW 4Gbps SFP transceiver pair |
| 线缆 | ||
| 5601 |
19K1247 19K1265 39M5696 39M5699 |
1M LC-LC Fibre Optic Cable (Withdrawn) |
| 5605 |
19K1248 19K1266 39M5697 39M5700 |
5M LC-LC Fibre Optic Cable (Withdrawn) |
| 5625 |
19K1249 19K1267 39M5698 39M5701 |
25M LC-LC Fibre Optic Cable (Withdrawn) |
| 其它 | ||
| 2010 | DS4700/EXP810 Telco Bezel (Withdrawn) |
